Rotary Spin Coating System for Sustainable Pulp Molded Products
Detail produk:
| Tempat asal: | CINA |
| Nama merek: | OSMANUV |
| Sertifikasi: | ISO9001 |
| Nomor model: | OSM-XT-3200T |
| Dokumen: | Version 2.0 of 24-station s...on.pdf |
Syarat-syarat pembayaran & pengiriman:
| Kuantitas min Order: | 1 set |
|---|---|
| Harga: | negotiable |
| Kemasan rincian: | Kemasan kayu |
| Waktu pengiriman: | 60 hari |
| Syarat-syarat pembayaran: | T/t |
| Menyediakan kemampuan: | Perundingan |
|
Informasi Detail |
|||
| Voltase: | 220V, 380V, 380V/220V, 220V/380V, 380V/50Hz | Kondisi: | Baru |
|---|---|---|---|
| Layanan purna jual disediakan: | Insinyur tersedia untuk mesin layanan di luar negeri, dukungan teknis video, dukungan online, dukung | dimensi (l*w*h): | Ukuran khusus, 2580*1130*1140mm, 1000*2575*1750mm, 1200*620*550mm (l*w*h), 1030*1000*620mm |
| Jaminan: | 1 Tahun, Satu Tahun, 12 bulan | Kekuatan: | 3KW, 16KW, 65.3kW, 4.2kw, 0.75kW/220V/50Hz |
| Nama Produk: | Garis mesin pelapis putaran 24-stasiun | Kecepatan: | Bisa disesuaikan |
| Menyoroti: | rotary spin coating system for pulp molding,biodegradable film precision application machine,pulp molding coating machine with warranty |
||
Deskripsi Produk
Rotary Spin Coating System for Sustainable Pulp Molded Products
Composition of Production Line:
This precision line features a servo-driven indexing system, 24 individually programmable stations, high-precision ultrasonic spray or low-flow spray valves for minimal waste, a controlled climate pre-dry zone, a energy-efficient IR drying machine, and a final cooling conveyor.
Product Description:
This advanced rotary spin coating line is designed for applying the latest biodegradable, compostable, or UV-curable coatings to premium and sustainable pulp packaging. It focuses on precision application to minimize material usage—a critical cost factor for specialty coatings—while ensuring perfect performance. Ideal for high-value products in the electronics, cosmetic, and organic food sectors.
Technical Parameters:
| Parameter Category | Details & Specifications |
|---|---|
| Model | OSM-XT-3200T |
| Suitable Product | Premium Pulp Packaging, Electronics Trays, Cosmetic Containers |
| Number of Stations | 24 |
| Coating Technology | Programmable Ultrasonic Spray / Low-Flow Spin Coating |
| Coating Type | Biodegradable (PLA, PHA), Water-Based, UV-Curable |
| Curing Method | Customizable (UV-LED, NIR, or Low-Temp Hot Air) |
| Control System | Advanced PLC with IoT connectivity for data monitoring |
| Coating Weight Accuracy | ±2% |
Application:
Applying ultra-thin, functional barriers and aesthetic coatings to premium pulp molded products requiring home or industrial compostability certifications.
Customization:
Highly customizable based on coating chemistry. Options include ultrasonic spray heads for ultra-low viscosity materials, UV-LED curing for instant cure, or NIR for gentle drying of heat-sensitive biopolymers.
Feature:
- Precision Application: Ultrasonic spin coating technology drastically reduces overspray and material consumption.
- Sustainable Focus: Compatible with the latest bio-based and compostable coating formulations.
- Gentle Curing: UV-LED or NIR options prevent thermal degradation of sensitive pulp substrates.
- Data Tracking: IoT connectivity allows for monitoring of production metrics and quality control.
Support and Services:
Extensive application development support, partnership with coating material suppliers, and remote diagnostics.
Packing and Shipping:
High-precision spray valves are shipped in separate, shock-proof packaging. The entire system is covered for dust and moisture protection.
FAQ:
Q: Can this line handle very thin, water-based coatings without clogging?
A: Yes. The ultrasonic spin coating technology is specifically designed for low-viscosity, particle-free fluids and is far less prone to clogging than conventional air spray nozzles, ensuring consistent application and minimal maintenance.
