Bagasse Tableware Single Station Spin Coating Sample Testing Machine for Biodegradable Materials
Detail produk:
| Tempat asal: | Tiongkok |
| Nama merek: | OSMANUV |
| Sertifikasi: | CE |
| Nomor model: | OSM-XT-450T |
| Dokumen: | CE-Single station spin caot...ne.pdf |
Syarat-syarat pembayaran & pengiriman:
| Kuantitas min Order: | 1 set |
|---|---|
| Harga: | Negotation |
| Kemasan rincian: | Kemasan kayu |
| Waktu pengiriman: | 30 Hari |
| Menyediakan kemampuan: | Perundingan |
|
Informasi Detail |
|||
| Nama Produk: | Mesin pelapis putar stasiun tunggal | Dimensi (P*L*T): | Ukuran Khusus, Kotak 700mm L*420mm W*1135mmH：400mm*400mm*500mm |
|---|---|---|---|
| Kecepatan Putar: | dapat disesuaikan, 1150 rpm (kecepatan maks) | Voltase: | 380V/50Hz |
| Berat: | Berat bersih: 120 kg; Berat Kotor: 130 kg | Kekuatan: | 500W |
| Jaminan: | 1 tahun | Kondisi: | BARU |
Deskripsi Produk
Bagasse Tableware Single Station Spin Coating Sample Testing Machine for Biodegradable Materials
Product Description
This single station spin coater is specifically designed for coating sample development and performance testing on bagasse tableware and food packaging products. The equipment enables precise evaluation of coating formulations through controlled spin coating processes using eco-friendly water-based coatings.
Technical Parameters
| Parameter | Specification |
|---|---|
| Model | OSM-XT-450T |
| Maximum Sample Diameter | 380 mm (Customizable) |
| Rotation Speed Range | 100-1150 RPM (Customizable) |
| Coating Uniformity | ±2% thickness variation |
| Control Accuracy | ±0.5% speed stability |
| Power Requirements | 380V/50Hz |
Application
Coating sample preparation and performance testing for bagasse tableware, food containers, and sustainable packaging prototypes.
Customization
-
Customizable sample holding fixtures for various shapes
-
Customizable coating thickness monitoring system
-
Customizable data logging and export functions
Feature
-
Precise coating thickness control
-
Excellent process repeatability
-
User-friendly operation interface
-
Compact laboratory design
Support and Services
-
Installation and commissioning support
-
Operation training program
-
12-month warranty coverage
-
Technical application support
Packing and Shipping
-
Laboratory-grade protective packaging
-
Shock-absorbent foam materials
-
Climate-controlled shipping option
FAQ
Q: What coating thickness range can be achieved?
A: The system can achieve coating thickness from 5 to 200 microns with high uniformity and repeatability.
